VO 06-300 reverse (VO 13-290) #12.5 w/motor AIR 112 MB8 3 kW 750 rpm

The axial reversible fan of the VO 06-300 (VO 13-290) #12,5 (VO 12-300) series with an electric motor Electric motor AIR 112 MV8 3.0 Power kW 750 Vol./Min is intended for general industrial use and made of carbon steel.

This reversible axial fan moves air or gas along the axis of the impeller — both towards and away from the motor — without changing its aerodynamic characteristics. The mirror arrangement of 6 blades in a 3+3 configuration on the hub ensures 100% reversibility, which is the maximum efficiency for reversible fans. It is used in ventilation or air heating systems and for transporting non-aggressive gas mixtures at temperatures from -40 °C to +40 °C (up to +45 °C for tropical versions), free from dust and solid particles exceeding 10 mg/m³, as well as fibrous and sticky substances.

Suitable for moderate (U) and tropical (T) climates, placement category 2.

RMS vibration velocity does not exceed 6.3 mm/s. Installation on objects with vibration speeds over 2 mm/s is not allowed.

Should be installed in locations protected from atmospheric precipitation.

This model is an analogue of VO 12-300, VO 13-300, VO 12-290, VO 12-330, VO 13-290, VO 14-300, VO 14-320, VO 13-320 axial fans.

The axial fan VO 06-300 (VO 13-290) #12,5 (VO 12-300) consists of the following components (available separately):

• axial fan without motor;
• fan impeller;
• fan casing (shroud);
• electric motor Electric motor AIR 112 MV8 3.0 Power kW 750 Vol./Min for the fan VO 06-300 (VO 13-290) #12,5;

General information about VO 06-300 reverse (VO 13-290) #12.5 w/motor AIR 112 MB8 3 kW 750 rpm (VO 12-300) axial fans:

• low pressure;
• single-side suction;
• 6 blades;
• right-hand rotation;
• material: carbon steel (optional: stainless steel, aluminum alloys, other metals);

Application: Air heating, supply and exhaust ventilation, air conditioning, and technological installations that do not involve explosive substances. Also suitable for mechanical engineering, residential air systems, and sanitary or industrial purposes.

• air conditioning systems;
• supply and exhaust ventilation systems;
• air heating systems;
• technological installations;
• other sanitary and industrial applications.

Purpose of VO 06-300 / VO 12-300 reversible fans:

Used in ventilation and air heating systems for gases non-aggressive to carbon steel at -40 °C to +40 °C (up to +45 °C for tropical use), free of dust, sticky substances, and solid particles over 10 mg/m³.

Design and operation principle:

The impeller is mounted directly on the motor shaft. The casing is cylindrical, with flanges on both sides for duct connection. A support bracket is included for installation. The impeller includes a shroud, disk, hub, and 6 welded blades. Right-hand rotation is standard.

Air is moved by transferring rotational energy from the impeller driven by the electric motor along the axial direction.

Delivery set for axial fan VO 06-300 (VO 13-290) #12,5 (VO 12-300) with motor:

• cylindrical housing with flanges;
• impeller mounted on motor shaft;
• electric motor Electric motor AIR 112 MV8 3.0 Power kW 750 Vol./Min;
• support bracket (base) for mounting.
