VC 10-28 Radial Fans are industrial medium-pressure centrifugal units designed for ventilation and air heating systems. They feature high durability, precision impeller balancing, and continuous duty performance. Perfect for moving clean or slightly dusty air in diverse industrial environments.
9900
6800
6000
1430
3800
400
5000
4400
2200
2750
1400
590
2500
2500
1150
1300
1050
1400
640
1450
570
470
Radial Medium Pressure Fans VC 10-28: A Proven Classic of Industrial Ventilation
The VC 10-28 series belongs to modern solutions in industrial aerodynamics, combining efficiency, precision, and durability. Thanks to a balanced design and sophisticated technical solutions, these centrifugal fans demonstrate a stable efficiency (coefficient of performance). They are designed for long-term operation in production environments where reliability and stability of airflows are valued.
What are VC 10-28 Medium Pressure Fans and Their Purpose
VC 10-28 fans are manufactured according to TU U 28.2-24881057-003:2023. They are intended for moving air and gas mixtures without aggressive impurities and with temperatures not exceeding +80 °C. The permissible concentration of sticky, fibrous, and dust contaminants in the air must not exceed the threshold of 100 mg/m³. All models in the series feature an AC electric motor that transmits torque without energy loss. The VC 10-28 radial fan can be equipped with a general-purpose three-phase asynchronous motor or its explosion-proof modification. This approach allows the equipment to be adapted to various technological conditions and types of production facilities.
|
VC 10-28 Radial Fan Models |
Power kW |
Rotation Speed rpm |
Capacity m³/h max |
Pressure, Pa max |
|---|---|---|---|---|
| №2.5 | 0.12 | 1500 | 391 | 390 |
| №2.5 | 1.1 | 3000 | 820 | 1684 |
| №3.15 | 0.37 | 1500 | 800 | 640 |
| №3.15 | 4 | 3000 | 1670 | 2821 |
| №4 | 2.2 | 1500 | 1840 | 1095 |
| №4 | 11 | 3000 | 3820 | 4745 |
| №5 | 5.5 | 1500 | 3310 | 1757 |
| VC 10-28 №5 | 37 | 3000 | 6810 | 7420 |
Materials from which the medium pressure centrifugal fan can be made: carbon or stainless steel, aluminum alloys, dissimilar metals.
Design Characteristics and Technical Capabilities of the VC 10-28 Series
The design of VC 10-28 fans is thought out to the smallest detail, ensuring efficient air movement with minimal energy consumption. Parameters characterizing the VC 10-28 radial fan:
- Uniformity of air flow supplied by an impeller with forward-curved blades;
- Balanced impeller rotation with minimal vibration;
- Reduced noise level due to precise housing element placement;
- Support for right-hand or left-hand rotation for installation convenience;
- Adaptation for working with air containing small amounts of dust and other solid impurities;
- Use of an electric motor with overheat protection and stable power;
- Reliable fasteners for securing the impeller at high speeds;
- Compatibility with air heating and air conditioning systems.
The combination of design solutions ensures unit operation in various load modes. The series fans demonstrate reliable performance even during long-term operation. Thanks to balancing precision, all system elements work in coordination without overloads or efficiency loss.
Main Advantages of VC 10-28 Fans
VC 10-28 fans have increased resistance to loads, making them indispensable for continuous technological processes. Ventilation equipment performance is optimized through precise impeller geometry and rational air flow distribution. Every centrifugal fan features a balanced design that minimizes vibrations. Advantages of VC 10-28 radial fans:
- Durable housing;
- Stable pressure parameters;
- Low noise level;
- Economical energy consumption;
- Universal installation;
- Durability of components;
- Precise element balancing;
- Easy access for cleaning.
Uniform pressure distribution is achieved due to the sophisticated aerodynamic profile of the VC 10-28 fan. The series effectively operates in medium-density air movement mode. Centrifugal fans made of carbon steel and other materials are not afraid of long-term use in active mode and sharp temperature drops, thus they are used in air heating systems. The factory quality guarantee confirms the durability and reliability of KVZ units. Decided to buy a VC 10-28 radial fan in Kyiv? Find the required model in the Ventilator.ua online store catalog. Delivery across Ukraine will allow receiving the ordered VC 10-28 fan in any region: Kyiv, Lviv, Odesa, Kharkiv, or Dnipro.
Where VC Medium Pressure Fans are Used
The scope of application for VC 10-28 medium pressure fans covers industrial and communal facilities. They are often installed in air supply systems for drying chambers, metallurgical, and chemical industries. VC 10-28 radial fans effectively work in technological processes of conditioning or removal of gas impurities. In series models, the impeller has special-shaped blades, contributing to uniform air movement. Due to resistance to various aggressive environments, these units are used in painting, boiler, and ventilation installations. An industrial VC 10-28 radial fan provides continuous air supply, maintaining stability of pressure parameters.
Popular VC 10-28 Models
Popular models among Ventilator.ua customers include VC 10-28 (VR 200-28) №5 with AIR 200 M2 37 kW 3000 rpm motor, and variations №3.15 and №2.5 at 1500 rpm. All devices are manufactured as single-sided suction type and assembled according to configuration scheme №1. They have electric motors of various capacities and different impeller rotation frequencies (right and left side). A wide range of performance characteristics allows buyers to select a fan for their needs with maximum precision. The VC 10-28 (VR 200-28) №5 centrifugal fan at 3000 rpm is equipped with a powerful AIR 200 M2 37 kW motor and used for stable air supply in large premises. The model is optimized for industrial workshops with high air exchange requirements. VC 10-28 (VR 200-28) №3.15 with AIR 63 B4 0.37 kW 1500 rpm motor is suitable for medium-load installations and process ventilation systems. The smallest fan model — VC 10-28 (VR 200-28) №2.5 with AIR 56 A4 0.12 kW 1500 rpm motor — stands out for its compactness and low noise level. All three VC 10-28 variants feature precise balancing, guaranteeing long-term operation according to the fan's technical specifications.
How to Choose a VC Medium Pressure Fan for Your Needs
Selecting a VC 10-28 fan model depends on operating conditions, pressure levels, air volume, and network parameters. For small production rooms, VC 10-28 №2.5 is suitable, where compactness and low energy consumption are important. If the system requires increased air flow, VC 10-28 №3.15 with a 0.37 kW motor is the optimal choice. For powerful ventilation complexes, VC 10-28 №5 is better, providing a high pressure level at high speeds. Be sure to consider the rotation direction (right/left) of the impeller, as this affects duct connection convenience. It is also important to check the unit's parameters against the temperature regime and air composition.
We Invite You to Buy VC 10-28 Fans at Ventilator.ua
The Ventilator.ua online store catalog presents high-quality VC 10-28 radial fans. The company offers a full range of models from the KVZ plant with an official manufacturer's warranty. To buy a VC 10-28 medium pressure fan in Kyiv quickly and conveniently — order the required model made of aluminum alloys or steel at Ventilator.ua. On the website, you can buy VC with specialist consultation and a full package of documents. The store's offer includes — a wide choice of models, the best price, and delivery throughout Ukraine.
